IS 3224
Valve fittings for compressed gas cylinder excluding liquefied petroleum gas cylinders
Summry
Valve fittings for compressed gas cylinders are mechanical devices attached to cylinders to control the release, flow, and safety of gases such as oxygen, nitrogen, and industrial gases, excluding liquefied petroleum gas (LPG). They ensure safe handling, proper pressure regulation, and leak prevention during storage, transport, and usage.
Why BIS Certificate is Mandatory for Valve Fittings for Compressed Gas Cylinders (excluding LPG cylinders)?
BIS certification is mandatory to ensure valve fittings meet Indian safety and quality standards. These fittings handle high-pressure gases, and substandard materials can cause leaks, explosions, or accidents. BIS compliance guarantees mechanical strength, leak-proof design, corrosion resistance, and reliability, protecting both users and industrial operations.
What is BIS Certified for Valve Fittings for Compressed Gas Cylinders (excluding LPG cylinders)?
A BIS Certificate confirms that valve fittings comply with the relevant Indian Standard (IS 3224 – Valve Fittings for Compressed Gas Cylinders). It verifies quality, safety, and performance requirements, ensuring the product is manufactured from approved materials, tested for pressure resistance, leak-proof performance, and suitable for safe industrial and medical applications.
Test required For Valve Fittings for Compressed Gas Cylinders (excluding LPG cylinders)
Requirements for electroplating (on medical cylinder valves only) Coating requirement
| Title | Mandatory/Optional |
|---|---|
| Appearance | Required |
| Thickness | Required |
| Ductility | Required |
| Adhesion | Required |
| Corrosion resistance | Required |
MATERIAL
| Title | Mandatory/Optional |
|---|---|
| Valve Body (Chemical composition) | Optional |
| Tensile Strength and Elongation | Required |
| Impact Strength | Required |
| Other metallic and Nonmetallic components | Optional |
Valve design Qualification tests (Type Tests)
| Title | Mandatory/Optional |
|---|---|
| Hydraulic Burst Pressure | Required |
| Valve Impact tes | Required |
| Valving Torque test | Required |
| Excessive Torque test | Required |
| Internal/External leak tightness | Required |
| Endurance test | Required |
| Visual examination | Required |
| Flame impingement (For hand wheel Knob operated Valves) | Required |
| Flow capacity of PRD | Required |
Type tests for PRD of CNG Valves
| Title | Mandatory/Optional |
|---|---|
| Resistance to extrusion test | Required |
| Accelerated life test | Required |
| Continued Operation (Cyclic) test | Required |
| Thermal Cyclic tes | Required |
| Condensate corrosion resistance test | Required |
| Vibration test | Required |
| Leakage test | Required |
| Activation test | Required |
Type test for excess flow valve for CNG Valves
| Title | Mandatory/Optional |
|---|---|
| Type tests for excess flow valve for CNG Valves | Required |
Production Inspection and Testing
| Title | Mandatory/Optional |
|---|---|
| Internal and External leak tightness test | Required |
| Bursting pressure of Bursting disc of PRD | Required |
| Yield temperature of fusible plug | Required |
| Valve inlet connection | Required |
| Valve Outlet connection | Required |
| Checking of other dimensions | Required |
Benefits of BIS Certification for Valve Fittings for Compressed Gas Cylinders (excluding LPG cylinders)
1. Safety Assurance: BIS-certified valve fittings are tested for high-pressure resistance, leak prevention, and corrosion resistance, reducing the risk of accidents.
2. Quality Compliance: Certification guarantees adherence to IS 3224 standards, ensuring uniformity in materials, dimensions, and workmanship across all fittings.
3. Legal Market Access: BIS certification is mandatory in India, allowing manufacturers and importers to sell valve fittings without regulatory penalties or product rejection.
4. Consumer and Industry Trust: Industrial users, hospitals, and gas suppliers prefer BIS-marked fittings, ensuring confidence in safe and reliable operation.
5. Durability and Performance: Certified fittings provide long-term durability, reliable flow control, and maintenance-free operation, reducing replacement costs and supporting efficient gas handling in industries and medical facilities.
