IS 12640 (Part 2)
Electrical - Residual current operated circuit breakers for household and similar uses–Part 2 Circuit breakers with integral overcurrent protection(RCVOs)
Summary
Residual Current Operated Circuit Breakers with Integral Overcurrent Protection (RCBOs) are electrical safety devices that combine protection against earth leakage, overload, and short circuits in a single unit. They are commonly used in household and similar electrical installations to prevent electric shock and fire hazards.
Why BIS Certificate is Mandatory for Residual Current Operated Circuit Breakers With Integral Overcurrent Protection for Household & Similar Uses (RCBOs) ?
BIS certification is mandatory for RCBOs to ensure electrical safety, reliability, and compliance with Indian Standards. These devices protect human life from electric shock and fire risks. Mandatory certification prevents the sale of unsafe or substandard products in the Indian market.
What is BIS Certified for Residual Current Operated Circuit Breakers With Integral Overcurrent Protection for Household & Similar Uses (RCBOs) ?
RCBOs must comply with IS/IEC 61009-1, the Indian Standard specified by BIS. This standard defines requirements for design, performance, rated current, breaking capacity, leakage sensitivity, endurance, and safety tests, ensuring reliable protection in household and similar electrical installations.
Test required For Residual Current Operated Circuit Breakers With Integral Overcurrent Protection for Household & Similar Uses (RCBOs)
| Title | Mandatory/Optional |
|---|---|
| Tripping test | Required |
| Required | |
| Performance of the test device | Required |
| Marking (except indelibility of marking) | Required |
| Mechanical Design (General) | Required |
| Mechanical Design (Mechanism) | Optional |
| Indelibility of marking | Required |
| Clearance & creepage distances (external parts) | Required |
| Non interchangeability | Required |
| Trip-free mechanism | Required |
| Reliability of Screws, current-carrying parts and connections | Required |
| Reliability of Terminalsfor external conductors | Required |
| Protection against electric shock | Required |
| Resistance to heat | Optional |
| Clearance & Creepage distances (internal parts) | Required |
| Resistance to rusting | Optional |
| Resistance to abnormal heat and to fire | Optional |
| Resistance of the insulation of open contacts and basic insulation against an impulse voltage in normal conditions | Required |
| Verification of the behavior of components bridging the basic insulation | Required |
| Resistance to humidity | Required |
| Insulation resistance of the main circuit | Required |
| Dielectric Strength of the main circuit | Required |
| Insulation resistance and dielectric strength of auxiliary circuits | Required |
| Verification of clearances with the impulse withstand voltage | Required |
| Secondary circuit of detection transformers | Required |
| Capability of control circuits connected to the main circuits | Required |
| Temperature rise | Required |
| Reliability at 40°C | Required |
| Ageing of electronic components | Required |
| Mechanical and electrical endurance | Required |
| Residual Operating characteristic | Required |
| Behavior in the case of failure of line voltage | Required |
| Unwanted tripping Behavior in the case of surge currents | Optional |
| Performance at IΔm | Optional |
| Test device | Required |
| Resistance to mechanicalshock and impact | Required |
| Non-operating current under overcurrent conditions | Required |
| Verification of the suitability of RCCBs for use in IT systems | Optional |
| Coordination at Inc | Optional |
| Overcurrent operating characteristics | Optional |
| Short-circuit performance at 1500A | Optional |
| Performance at service short-circuit capacity | Optional |
| Reliability (climatic test) | Optional |
| Electromagnetic Compatibility | Optional |
Benefits of BIS Certification for Residual Current Operated Circuit Breakers With Integral Overcurrent Protection for Household & Similar Uses (RCBOs)
1. Enhanced Electrical Safety - BIS-certified RCBOs provide assured protection against electric shock, short circuits, and fire hazards, safeguarding users and property.
2. Quality and Performance Assurance - Certification confirms compliance with strict testing for durability, breaking capacity, and leakage sensitivity, ensuring long-term reliable operation.
3. Legal Compliance in India - BIS certification is compulsory, allowing manufacturers and importers to legally sell RCBOs without regulatory issues or penalties.
4. Consumer Trust and Market Acceptance - The BIS mark builds confidence among consumers, electricians, and builders, leading to higher acceptance in residential and commercial projects.
5. Competitive Advantage and Brand Value - BIS-certified RCBOs gain preference in government tenders, real estate projects, and organized retail, strengthening brand reputation and market reach.
